■ Leveling accuracy1,3: ± 1.5 mm/30 m,
1/16“ @ 100 ft, 10 arc seconds
■ Operating diameter1,2: appr. 800 m (2600 feet)
■ Rotation: 0, 10, 80, 200, 600 rpm
■ Pre-selected scan sizes: 5°, 15°, 45°, 90°, 180°
and 0
■ Laser type: red diode laser 600-680 nm
■ Laser class : Class 3A/3R, max. 5 mW
■ Self-leveling range: ± 5° (±9%)
■ Leveling indicators: LED flashes
■ Radio range (HL760): up to 100 m (330 ft)
■ Power source: 10.000 mAh NiMH battery pack
■ Battery life1
: 45 hours NiMH; 60 hours alkaline
■ Operating temp.: -20°C to 50°C (-4°F to 122°F)
■ Storage temp.: -20°C to 70°C (-4°F to 158°F)
■ Tripod attachments:
5/8 x 11 horizontally and vertically
■ Dust and waterproof: Yes - IP66
■ Weight: 3.1 kg (6.8 lbs)
■ Low voltage indication: LED battery indicator
■ Low voltage disconnection: unit shuts off
■ Warranty: 5 Years
HL760 Digital Readout Receiver
■ Highly versatile receiver for basic and advanced
leveling and aligning applications
■ Works with HV302 in automatic Grade Match
and PlaneLok applications
■ Key Features:
- Digital readout of elevation
- Exact distance from on-grade displayed
- Anti-strobe sensor to prevent false reading
from jobsite strobe lights
- Large reception height to ease beam reception
- Withstands a drop of up to 3 m (10 ft)
- Fingerprint function - detects only the laser
beam of the paired transmitter
■ User Benefits:
- No need to go “on-grade” to measure;
- Saves considerable time
- Reduces rework by allowing remote monitoring
- Increases reliability, accuracy and durability
RC402N Remote Control Specifications
■ Operating range1,3: up to 100 m (330 ft)
■ Power source: 2 x 1.5V AA alkaline batteries
■ Battery life1
: 130 hours
■ Dust and waterproof: Yes - IP66
■ Weight: 0.26 kg (0.57 lbs)
HL760 Digital Readout Receiver
Specifications
■ Digital readout units: mm, cm, ft, in, frac. in
■ Reception height: 127 mm (5 inches)
■ Six On-grade sensitivities:
- Ultra Fine 0.5 mm (~1/32 in)
- Super Fine 1 mm (~1/16 in)
- Fine 2 mm (~1/8 in)
- Medium 5 mm (~1/4 in)
- Coarse 10 mm (~1/2 in)
- Calibration Mode 0.1 mm (~1/64 in)
■ Battery life (2 x AA):
60+ hours continuous operation
■ Auto shut-off: 30 minutes/24 hours
■ Operating temp.: -20°C to 50°C (-4°F to 122°F)
■ Dust and waterproof: Yes - IP67
■ Weight: 0.37 kg (13.1 oz)
